AIR-ANT5135D-R Cisco Aironet 5GHz 3.5dBi Dipole Antenna

Overview of Cisco AIR-ANT5135D-R 5GHz 3.5 dBi Antenna

The Cisco AIR-ANT5135D-R is a high-performance 5 GHz omni-directional dipole antenna engineered to improve wireless signal distribution for compatible Cisco Aironet wireless access points. Designed for enterprise, educational, healthcare, government, and commercial wireless deployments, this antenna delivers dependable RF coverage while maintaining consistent network performance in demanding indoor environments.

General Information

• Brand: Cisco
• Part Number: AIR-ANT5135D-R
• Product Type: Omni-directional Dipole Antenna

Technical Specifications

• Frequency Band: 5 GHz
• Antenna Gain: 3.5 dBi
• Connector Type: RP-TNC
• Height: 5.3 inches
• Width: 0.6 inches
• Weight: Approximately 1 ounce

Key Features of the Cisco AIR-ANT5135D-R

• Optimized for enterprise-grade wireless deployments.
• Supports dependable 5 GHz WLAN performance.
• Ideal for professional indoor installations.
• Improves wireless signal consistency.
• Compatible with selected Cisco Aironet access points.

Approximate Indoor Coverage

• Up to approximately 675 feet at 6 Mbps.
• Up to approximately 75 feet at 54 Mbps.

Compatible Models

• Cisco Aironet 1200 Series Access Points.
• Cisco Aironet 1230AG Series Access Points.
• Systems equipped with the RM22A radio module.

Space-Efficient Dimensions

• Height: 5.3 inches
• Width: 0.6 inches
• Compact cylindrical profile
• Suitable for professional indoor installations

Enterprise-Class Reliability

• Designed specifically for Cisco wireless infrastructure.
• Stable omni-directional RF coverage.
• Professional-grade construction quality.
• Dependable enterprise wireless performance.
• Optimized 5 GHz operation.
• Compact and lightweight design.
• Easy RP-TNC connectivity.
• Suitable for long-term deployments.

Ideal Deployment Scenarios

• Business offices
• Conference facilities
• Educational campuses
• Healthcare environments
• Retail locations
• Warehouses
• Manufacturing facilities
• Hospitality venues
• Government offices
• Commercial buildings

Deployment Recommendations

• Confirm access point compatibility before installation.
• Install the antenna according to recommended orientation guidelines.
• Position the antenna away from large metal objects whenever possible.
• Perform a wireless site survey for optimal placement.
• Follow enterprise wireless best practices for maximum coverage.
